    300*150mm Digital Horizontal Profile Projector with LED illumination and Colorful DP400

    Ask Lasest Price
    Brand Name : Sinowon
    Model Number : PH400-3015
    Certification : CE
    Price : Negotiate
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 15 sets per month
    Delivery Time : 15 days
    • Product Details
    • Company Profile

    300*150mm Digital Horizontal Profile Projector with LED illumination and Colorful DP400


    Ø400mm Digital Horizontal Profile Projector PH400-3015



    • Features:
    1. The lifting system adopts cross roller rail and precision screw drive, which makes lifting drive more comfortable and stable;
    2. Coating process reflector, clearer image and great dustproof;
    3. Adjustable contour and surface illumination, to meet with difference workpiece demand;
    4. Imported high light and long using life LED illumination ,to ensure precision measurement demand;
    5. High resolution optical system with clear image and magnification error is less than 0.08%;
    6. Powerful Bi-axial fan cooling system,highly increase using life;
    7. Powerful and colorful DRO DP400,realized fast and accurate 2D Measurement;
    8. Built-in Mini-printer, can print and save data;
    9. With standard 10X objective, optional 5X,20X,50X,100X objective,rotary table, foot switch ,clamp, etc.

    • Specification:
    Product NameØ400mm Digital Horizontal Profile Projector
    ModePH400-3015
    Code #512-400
    Working Stage Size455x126mm
    Working Stage Travel300x150mm
    Focusing120mm
    Accuracy≤3+L/200(um)
    Resolution0.0005mm
    Loading Weight15Kg
    ScreenDia:412mm,Measurement Range ≥ Ø400
    Rotation Angle 0~360° ;Resolution: 1’or 0.01°,accuracy 6’
    Digital ReadoutDP400 (510-340)Multifunction colorful LCD digital readout
    Illumination

    Contour Illumination:3.2V/10W LED
    Surface Illumination:220V/130W LED

    Working EnvironmentalTemp:20℃±5℃,Humidity:40%-70%RH
    Power SupplyAC110V/60Hz; 220V/50Hz,200W
    Dimension (L×W×H)1099 x 1455 x 633mm
    Package Dimension(L×W×H)1157x1355x653mm
    Gross/Net Weight350/300kg


    • Optional Objectives:

    Magnification5X10X20X50X
    Field of Viewφ80mmφ40mmφ20mmφ8mm
    Working Distance65mm80mm67.7mm51.4mm


    • Company Profile:


    More details of PH400-3015 : Digital Horizontal Profile Projector PH400-3015.pd...
