• With programmable surface 4-ring 8-division LED Cold Illumination and contour LED parallel illumination and internal intelligent light adjustment, it can automatic control the brightness in the 4-ring 8-division;
• Z-axis equipped with high accuracy linear guide and servo motor control system, realize auto focus measurement, and eliminate the human focus error, enhance measurement accuracy and stability;
• Powerful function iMeasuring2.2 Measuring Software, highly enhance the quality control;
• Optional FexQMS Measuring Data Analysis and Real-time monitoring software which enhance program control and reduce material consumption.
• High precision Jinan Qing marble base and pillar, to ensure high stability and accuracy;
• High precision toothless rod and fast moving locking device, to ensure hysterisis error is within 2um;
• High accuracy A grade optical linear scale with precision working stage, to ensure the accuracy is within 3+L/200um;
• High definitive detented zoom lens and high resolution color digital camera, to ensure clear image without distortion;

*L is measuring length,unit is mm, the mechanical accuracy of Z-axis and focus accuracy is greatly related to the surface of the workpiece.

**Magnification is approximate value, it is related to the dimension of monitor and resolution.
Customers can choose 0.5X or 2X optional objective, and realize image magnification: 13X~86X or 52X~344X.
