205,000 Measure / S High Accurary Optical Tracking Handheld 3D Scanning Equipment

DongGuan Sinowon Precision Instrument Co., Ltd. (2)
Contact Now
    Buy cheap 205,000 Measure / S High Accurary Optical Tracking Handheld 3D Scanning Equipment from wholesalers

    Buy cheap 205,000 Measure / S High Accurary Optical Tracking Handheld 3D Scanning Equipment from wholesalers
    • Buy cheap 205,000 Measure / S High Accurary Optical Tracking Handheld 3D Scanning Equipment from wholesalers
    • Buy cheap 205,000 Measure / S High Accurary Optical Tracking Handheld 3D Scanning Equipment from wholesalers
    • Buy cheap 205,000 Measure / S High Accurary Optical Tracking Handheld 3D Scanning Equipment from wholesalers

    205,000 Measure / S High Accurary Optical Tracking Handheld 3D Scanning Equipment

    Ask Lasest Price
    Brand Name : Sinowon
    Model Number : HyperScan 313
    Certification : CE
    Price : Negotiate
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 30 sets per month
    Delivery Time : 15 days
    • Product Details
    • Company Profile

    205,000 Measure / S High Accurary Optical Tracking Handheld 3D Scanning Equipment


    Optical tracking 3D scanner HyperScan , 717



    • Product Feature
    1. Measurement Volume: 17.6 m³ ;

    2. STAND-ALONE: No fixture;

    3. Dynamic Referencing;

    4. True Accuracy, Accuracy up to 0.02mm;

    5. Reliable equipment support Carbon fiber composite Archimedes structure;

    • Application


    • Specifications

    ModelHyperScan 717
    Weight1.5 kg
    AccuracyUp to 0.03mm
    Volume accuracy9.6 m20.086mm
    17.6m20.122mm
    Resolution0.05mm
    Measuring rate205,000 measure/s
    Laser area225×250 mm
    Reference distance300 mm
    Depth of focus250 mm
    TransmissionUSB 3.0
    Operating temperature0 - 40 ‍℃
    Operating humidity10 - 90%
    Output format.stl, .obj, .asc, .ply, .txt, . xyz etc., customizable
    Compatible software3DSystem (Geomagic Solution), InnovMetriv Software (PolyWorks) Dassault Systemes (CATIAV5 and SolidWorks), PTC (Pro/ENGINEER) Autodesk (Inventor, Alias, 3ds Max, Maya, Softimage) Siemens (NX and Solid Edge).

    More details can be found (PDF) : Optical tracking 3D scanner HyperScan.pdf
